100W IP66 LED Driver 24V 4A PFC 3 years warranty CEN-100-24

Click for original picture
Fob Price: 27.00 USD/
MOQ: 2
Payment Terms: delivery withindays since payment
Location: China
  Mr. Deric Ge    Contact Now 询价
Not exactly what you want? Post a quick Buying Request !


Product Detail

Brand:aa

Product detail:

Welcome to the world of MEAN WELL!

CEN-100-24







Product Pictures





Here is the detailed info for my 100W IP66 LED Driver 24V 4A  PFC 3 years warranty CEN-100-24 . Hope you like it.





Product Details







(AC Input Side View)







(DC Input Side View)







(Back View)







(input and output wires)







(Its Packing)







(48v version and 24v version)





Product Information



Features :



  • Universal AC input / Full range (up to 295VAC)
  • Protections: Short circuit /Over current /Over voltage /Over temperature
  • Output voltage and constant current level adjustable
  • Built-in active PFC function
  • IP66 design for indoor or outdoor installations
  • Class 2 power unit
  • Cooling by free air convection
  • 100% full load burn-in test
  • High reliablity
  • Suitable for LED lighting and moving sign applications
  • Compliance to worldwide safety regulations for lighting
  • Suitable for dry / damp / wet locations
  • 3years warranty

MODEL

CEN-100-24

OUTPUT

DC VOLTAGE

24V

Constant current operation voltage

15.6~24V

RATED CURRENT

4A

CURRENT

RANGE



0~4A

RATED POWER

96W

RIPPLE & NOISE (max.) Note.2

2.7Vp-p



VOLTAGE ADJ. RANGE



2227V



CURRENT ADJ. RANGE(SVR2)



2.64 A



VOLTAGE TOLERANCE Note.3

+/-10.0%

LINE REGULATION

+/-3.0%

LOAD REGULATION

+/-5.0%

SETUP TIME

3000ms/230VAC

5000ms / 115VAC    at full load

INPUT

VOLTAGE RANGE

90 ~ 295VAC          127 ~ 417VDC

FREQUENCY RANGE

47 ~ 63Hz

POWER FACTOR (Typ.)

PF>0.97/115VAC, PF>0.95/230VAC, PF>0.92/277VAC at full load (Please refer to "Power Factor Characteristic" curve)



EFFICIENCY (Typ.)

89%

AC CURRENT (Typ.)

1.4A/115VAC          0.7A/230VAC

0.55A/277VAC

INRUSH CURRENT (Typ.)

COLD START 45A(twidth=85£g   s measured at 50% Ipeak) at 230VAC

LEAKAGE CURRENT

<0.75mA / 240VAC

OTHERS

MTBF

519.5K hrs min.      MIL-HDBK-217F (25¢J)

DIMENSION

195*62.5*40.5mm (L*W*H)

PACKING

0.6Kg; 24pcs/15.4Kg/1.11CUFT
