BLC/HLC/AWB/AGC/2D-DNR/D-WDR/ATR/OSD,sony effio dsp

Brand:aa

Product detail:

BLC/HLC/AWB/AGC/2D-DNR/D-WDR/ATR/OSD,sony effio 700tvl camera



Weatherroof IR Outdoor Camera

1/3" Sony CCD 480TVL,600TVL,650TVL,700TVL optional

BLC/HLC/AWB/AGC/2D-DNR/D-WDR/ATR/OSD

Motion Detection,Privacy Mask

0.3Lux (F1.2,50IRE, AGC ON ,color), 0Lux (F1.2,50IRE, AGC ON, IR LEDs ON)

Standard: 6mm fixed Lens (3.6mm /8mm optional)

Special smart IR technology to effectively avoid IR over-exposure

Black IR LEDs to improve IR performance largely

36PCS Black IR LEDs

IR LEDs distance: 30m

Built-in Auto IR Illuminator

Smart design and stylish structure

Slim, flexible bracket

DWS(Dual Windows Structure),Anti- IR Diffusion and Fog

IP67,Outdoor Installation

CTB (Cable Through Bracket)

Power: DC12V













GR-CW330
CCD sensor		1/3"Sony SUPER HAD CCD, Powerful DSP
Lens amount		Std. f=6mm F1.6 Fixed Lens (Option: 3.6mm/8mm F1.6)
Lens type		Fixed Lens (not c/cs amount)
Horizontal resolution		600TVL(Color), 650(B/W)	650TVL(Color), 700(B/W)	700TVL(Color), 780(B/W)
Effective pixels		NTSC:768H×494V	NTSC:768H×494V	NTSC:976(H)x494(V)
		PAL: 752H×582V	PAL: 752H×582V	PAL:976(H)x582(V)
S/N		More than 50dB(AGC OFF)
Low illumination		Color: 0.3Lux(F1.2,50IRE,AGC ON),D/N:0Lux(F1.2,50IRE,AGC ON,IR LEDs ON)
D/N		D/N Auto Converter
D/N switching method		D/N controlled by CDS
D/N switching time		000~255
Size description		Smart design
Whole body		Stylish structure
DWS		Dual windows structure
Bracket		CTB (Cable through bracket)
Body color		Metal gray, Lvory white optional
Waterproof rating		IP67
OSD menu		OSD control on power cable
DNR		3D-DNR optional	2D-DNR	2D-DNR
Sense up		Sense up optional	N/C	N/C
D-WDR		Yes
HLC		Yes
Gamma		N/C	N/C	Yes
Privacy		1~8		ON/OFF
MD		Yes
Color tint		N/C	N/C	Yes
BLC		Yes
Color adaptive		N/C	N/C	Yes
Brightness		0~255	0~255	0~255
White balance		AWB,ATW,MWB
Mirror		ON/OFF
Title settings		Yes
Title location		Selectable
IR LEDs		36PCS black LEDs
Smart IR		Yes
Infrared wavelength		850nm
IR distance		30m
IR objective angle		600 (F=6mm fixed lens)
IR LEDs ON/OFF		CDS auto control
Video output		VBS 1.0 VPP(75ΩLoad)
Video output		BNC output
DC type	Power	MAX. DC12V 460mA[5.5W]
	Power supply	DC12V 1.0A
Working temperature		-100C~+500C
Working humidity		20~80% (Non-condensing)
Storage temperature		-100C~+600C
Storage humidity		20~95%(Non-condensing)
Camera Dimensions		192mm(L)×80mm(W) ×72mm(H)
