high efficiency positive displacement flow meter(PD Flow Meter)

Click for original picture
Fob Price: 6900.00 USD/
MOQ: 1
Payment Terms: delivery withindays since payment
Location: China
  Ms. Smile Jia    Contact Now 询价
Not exactly what you want? Post a quick Buying Request !


Product Detail

Brand:aa

Product detail:

Positive displacement rotary vane flow meter



Advantage:



1. FMC series PD rotary vane meters are single case, angle-type, rotary vane, positive displacement meters.


2. Superior accuracy and a wide range of products from gasoline to kerosene to fuel oils can be metered.


3. Compact, versatile design can be readily fit into nearly all installations.


4. Low pressure drop meter results in low meter slippage and thus superior meter accuracy.


5. Long service life, low friction ball bearings, fixed cam-type timing, and rugged construction give sustained accuracy and long time operation.



Application:



Application includes: blending, batching, dispensing, inventory control,
and custody transfer of oils, solvents, chemicals, paints, fats and fertilizers.



Construction:







Technical Specification:



Model

FMC-50

FMC-80

FMC-100

Size

50mm / 2 "

80mm / 3 "

100mm / 4 "

Flow Rate Range(L/min)

38-380

75-750

150-1500

Max.Working Pressure

150PSI

Accuracy

±0.2%

Repeatability

0.07%



FMC-50 PD flow meter with mechanical register, printer, strainer, air eliminator
