Multifunction Monobloc Air to Water Heat Pump with COP 4.5, capacity 6~20kw

Brand:aa

Product detail:



Air souce heat pump Center air conditioning and hot water All in one - DAO-16HA/3

  Daishiba multifunction air source heat pump provides energy-efficient space heating, cooling and domestic hot water for residential and small commercial application. Using free renewable energy from the air the units are highly efficient with low running costs, low carbon emission and are able to be integrated with energy systems such as solar heater and boiler.



Main parts of Multifunction Air Source Heat Pump:

Flexible configuration

Daishiba heat pump can be installed in both new and renewal applications. If you already have the heating system there is no need to change it. Daishiba heat pump could be compatible with:

1) Floor heating and cooling

2) Fan-coils

3) Mixed installation for floor heating and fan-coils

4) Standard low temperature radiators

5) Thermal solar energy



Total solution for home and light commercial use

1) Domestic hot water all year round

2) Space heating in winter

3) Space cooling in summer







Specification - Multifunction Air Source Heat Pump - Monobloc System





TECHNICAL DATA			DAO-06HA	DAO-08HA	DAO-11HA	DAO-14HA	DAO-16HA/3	DAO-20HA/3
Heating	Nominal capacity	kW	7.2	9.77	10.59	14.35	17.29	21.13
	Power input	kW	1.55	2.25	2.5	3.27	3.82	4.95
	COP	W/W	4.65	4.34	4.24	4.39	4.52	4.27
Cooling	Nominal capacity	kW	6.8	7.28	8.36	12.79	16.96	20.33
	Power input	kW	2.19	2.07	2.29	3.35	4.45	6.37
	EER	W/W	3.11	3.51	3.65	3.82	3.81	3.19
DHW	Nominal capacity	kW	6.95	8.67	9.44	12.68	16.06	18.94
	Power input	kW	1.96	2.66	2.78	3.77	4.5	5.47
	COP	W/W	3.55	3.36	3.40	3.36	3.57	3.46
Power supply		V/Ph/Hz	220-240/1/50				380-415/3/50
Max. leaving water temperature (without using backup heater)		°C	58
Compressor		Type	Rotary			Scroll
		Brand	TOSHIBA			DAIKIN
Refrigerant type			R410A
Dimensions (Net)	HxWxD	mm	1067x1140x480		1170x450x1280	1477x1198x480	1477x1198x480
Net weight		kg	120	130	155	165	170	175
Features included:
ON/OFF or Inverter type			on/off unit
Plate heat exchanger			swep brand heat exchanger
3-way valve			switch from space heating/cooling to domestic hot water supply
Manometer			refrigerant/water pressure manometer
Stainless steel buffer tank			15L		20L
Expansion vessel			10 L
Electric heater			3*2kW
Castel safety valve			yes
Castel air purge valve			yes
Water flow switch			yes
Auto restart			yes
Capacities and power inputs based on the following conditions:  -   Heating: Water Inlet/Outlet temperature 30°C/35°C. Outdoor air dry bulb/wet bulb temperature 7°C/6°C  - Cooling: Water Inlet/Outlet temperature 23°C/18°C. Outdoor air dry bulb temperature 35°C - Domestic Hot Water: Water temperature in the tank 40°C. Outdoor air dry bulb/wet bulb temperature 7°C/6°C.





PRODUCTION PROCESS of Multifunction Air Source Heat Pump - Monobloc System

1)   Base plates go online

2)   Install compressors, condensers and evaporators

3)   Assemble and weld copper pipes

4)   Recharged with Nitrogen

5)   Water-inspection (Check if exist in air leakage)

6)   Discharge Nitrogen

7)   Vacuum air-removed

8)   Add refrigerant

9)   Halogen inspection

10)        Fix fan component

11)        Install electrical control

12)        Security checks (Insulation, Ground connection, Dielectric Strength test, Leakage)

13)        Run commodity inspection (The noise of components and parts, Function, Timing, shutdown, current, Difference in temperature)

14)        Stick nameplate and connection diagram

15)        Document attached (Product Manuals, instructions)

16)        Final inspection (Appearance parts)

17)        Packing

18)        Tape-out





 DAISHIBA is a professional company engaged in sales, R&D and production of refrigeration and heating products. We have rich experience in refrigeration and heating for many years. By years’ growth our product line covers full range:



Multifunction air to water heat pump, All in one domestic hot water heat pump, Split domestic hot water heat pump, Commercial hot water heat pump, Swimming pool heat pump, Multifunction water source heat pump, Water to water heat pump, DC inverter water to air heat pump and EVI air to water heat pump.



We'd like to serve our customers by providing unique high end products and high quality service.
