Product Detail

Brand:aa

Product detail:

High Speed Rewinder



The finishing section of paper machine can choose the onfeed or under feed rewinder. Usually, the rewinder working speed is three times than that of the paper machine.



The onfeed rewinder price is low, but because of the structure, the working speed cannot too high and the trim width cannot too widely. The bottom knife roll and the rider roll are public, so as for the advanced paper that has the sensitivity for the knife mark; it cannot use the onfeed rewinder.



Uaually, we use onfeed rewinder when the working speed is less than 1000m/min, the width is less than 4000mm and the paper surface requirement is not too high.

There have several aspects need to notice:

  1. Unwind section structure. The under reel (parent reel) diameter decide the unwind section structure and movement type. For the large-diameter and the large width reel, it should use the hydraulic pressure rather than manual way to control the parent reel movements.
  2. Tension control of the unwind section.The old onfeed rewinder unwind tension cannot control automatically. During the reeling process, the operator always needs to adjust the web tension by operating brake pressure of unwind roll continuously. It is break easily during reeling, the paper forms and quality cannot meet the requirements.

    Technical parameters:

    Equipment name

    Full-automatic toilet rewinding&perforating machine

    Type

    1092

    1575

    1880

    Size of body paper

    Φ800×1350mm

    Φ800×1750mm

    Φ800×2060mm

    Diameter of production

    Φ80-Φ150mm

    Φ80-Φ150mm

    Φ80-Φ150mm

    Size of paper core

    Φ30-Φ50mm

    Φ30-Φ50mm

    Φ30-Φ50mm

    Capcacity for 8 hours

    1.5-2.5T

    2.5-3T

    3-4T

    Power

    2.2kw

    3kw

    4kw

    Contour dimension

    (mm)

    5600×2000

    ×1500

    5600×2400

    ×1500

    5600×2700

    ×1500

    Weight(T)

    2.1T

    2.8T

    4.8T
