Product Detail

Brand:aa

Product detail:

              1.6 M,DX5 Best ECO Solvent Printer with CE

Product Feature
*The printing quality is competitive to the Japanese  eco solvent printers;
*Standard double printheads design, double printing speed compared with single printhead;
*Automatic feeding and collecting structure;
*Two printheads design with intelligent infrared heater and fan drying system;
*The machine through different quality tests is stable and competent enough for mass production requirement .
*1440dpi overturns the highest resolution of traditional printers which leads the resolution of large format outdoor printing to a new standard.


*Your new profit pattern will be established and new business opportunity

will be discovered.

*Support two rolls of media printing together, 50% enhanced in speed.

 Specification

ModelSeron-E160
PrintheadEpson DX5 (Micro piezo print head)
InksWater-based/Thermal transfer/Solvent-based
Maximum printing width160cm
Resolution540dpi,720dpi,1440dpi
Printing Speed (DX5*1)360X720dpi 17m2/h
360X1440dpi 12m2/h
720X1080dpi 10m2/h
720X1440dpi 8m2/h
Printing Speed (DX5*2)360X720dpi 34m2/h
360X1440dpi 24m2/h
720X1080dpi 20m2/h
720X1440dpi 16m2/h
Ink cassette capacity1000cc/color
Three heating sectionsPre-heater, printing bed heater, rear heater
Picture drying systemStandard configuration: Infrared heating with fan drying system
Auto feeding/collecting systemStandard configuration
Environmental conditionsTemperature15°C-35°C Relative Humidity:40%-65%
Dimensions(L*W*H)/Weight3090*830*1450mm/210kg



Advanced Software Functions

1.High-efficient printing
*rip while printing;
*print selected area;
*skip white in X and Y printing directions;
*auto media sensor for setting print origin automatically(3 picture positions: left, middle and right);

2.Printing quality enhanced
*three feather printing modes :moisted, gradient, wave;
*simple printhead calibration mode can be easily controlled by operators;
*micro adjustment of printhead voltage;

3.Human-based functions
*options of automatically sensing or manually setting media origin;
*adjustable speed during printing;
*operations both in computer interface and machine control panel;
*automatic and constant ink system cleaning function;

4.Ink saving function
*options for single head cleansing or double heads cleansing;
*options for light, medium and heavy printhead sucking;

5.Printhead lifespan prolonged
*All color channels can be exchanged freely so as to prolong the printhead lifespan.

Details & Spare Parts



Samples



FAQ

1.This is the first time I use this kind of machine,is it easy operate?

  There are english manual or guide video that show how to use machine.

  If  there is still have any question,we can talk from photo or skype.

2.If machine have any problem after i ordered it,what could I do?

  Free parts send to you in machine warranty period if machine have any problem.

  Free after-sales service life for machine,please feel free contact us if your machine have any problem.

3.MOQ?

  Our MOQ is 1 set machine.We could send machine to your country port directly,please tell us your port name.

  There will be best shipping freight and machine price send to you.
