Concrete roofing tiles making machine with low cost and capacity 3800-4300 pcs/day/008615896531755

Click for original picture
Fob Price: 100000.00 USD/
MOQ: 1
Payment Terms: delivery withindays since payment
Location: China
  Ms. ada yang    Contact Now 询价
Not exactly what you want? Post a quick Buying Request !


Product Detail

Brand:aa

Product detail:

 MYWJ-125D high speed mould pressing machine:



 high speed 8-10pieces of tiles can be molded in one minute.



 The machine putts the wet concrete into 130 ton pressure then filter pressed through molds in high quality.



So its rain-proof and wind-proof performance is very good.





Hydraulic system: it adopts Japan Yuken hydraulic system.





Mating: it adopts imported intelligent hydraulic system device and automatic oil pressure distributing which is advanced configuration in hydraulic system.





Work flow: the who line has four parts: barket conveyor, rooling mixer, dosing mixer, and the main machine. when the machine is working ,the barket convryor take the materials to the rooling mixer, the rooling mixer is used to seperate the big stone from the materials to stir the materials more evenly ang quickly. when it is well mixe ,the materials will be sent into dosing mixer. then,the materials will be press onto the molds and molding to tiles. after the tile is done, it will be put on the plate. one man remove the mold to out door area to have it dyied. after serval days, you can paint the tiles with any color you like.



Technological  Parameter

Model

MYWJ-125

Overall Dimension

3120×1750×2650 mm

Moulding Cycle

8-10 s

Moulding Pressure

1250 KN

Weight of Main Engine

5.5 t

Equipped Capacitor

5.5 kw

Production Capacity

3800-4000 pcs/day

Tile Size

424×377 mm







The Consist of machine



1.molding tile forming machine



2.wheel agitator



3.automatic weighing and feeding machine



4.bucket elevator



5.steel tile holder
