quality automatic welded breed cages mesh equipment

Click for original picture
Fob Price: 80000.00 USD/
MOQ: 1
Payment Terms: delivery withindays since payment
Location: China
  Mr. FZ welding    Contact Now 询价
Not exactly what you want? Post a quick Buying Request !


Product Detail

Brand:aa

Product detail:



quality automatic welded breed cage mesh equipment

Welding wire diameter 2.0-3.0(mm)
Welding mesh size 25X20(mm)
Welding width 1200(mm)





Fields of application: to weld the meshes for cultivating cages, various  pet's cages and

various meshes of small specification.







Product features:



1,CNC wheel-step is designed  to provide the mesh grid with high accuracy.



2,Electrode lifting system is able to extend electrode life.



3,Line wire vertical straightening system can straighten the wire in high quality.



4,Unique high speed air cylinder used on welding electrode can provide high reliability.



5,Welding pressure steplessly adjusting applies to multiple wire diameter.



6,High speed mesh cutting system.



7,There are two choices for traction of  mesh. One is single car  to draw, the other is two cars to do by turns.



8,Straightening and sending of cross wires are completed by the automatically high-speed feeding system.



9,It is the most important that the equipment has high efficiency and be able to produce the high-quality meshes.





Technical parameters

Model

DNW-CNC1000

DNW-CNC1200

DNW-CNC1500

Installed power(kva)

3*60

3*80

4*80

System coltagte(v)

380V 50Hz

380V 50Hz

380V 50Hz

Control voltage(v)

24V

24V

24V

Max.mesh width

1000

1200

1500

Line wire spacing

≥20mm steplessly adjustable

Cross wire spacing

≥25mm steplessly adjustable

Wire diameter(mm)

2-3

2-3

2-3

Max.welding capacity

3+3

3+3

3+3

Max.wlding speed(time/min)

40-60

40-60

40-60

Max.welding spot nos.(group)

21

24

31

Pressed air(MPa )

≥0.8

≥0.8

≥0.8

Wire feeding method

coil feeding

Caterconer accutracy

≤2

≤2

≤2

Welding material

galvanized wire or cold drawing steel wire













































Photos of some components



Refering photos



If you have different requirements other than the above types, please kindly inform us about it and we will offer the

solution for you. Believe that if you are in need of the welding machine, you can get the satisfied ones from us.
