reasonable welding reinforcing wire production line

Click for original picture
Fob Price: 100000.00 USD/
MOQ: 1
Payment Terms: delivery withindays since payment
Location: China
  Mr. FZ welding    Contact Now 询价
Not exactly what you want? Post a quick Buying Request !


Product Detail

Brand:aa

Product detail:





reasonable welding reinforcing wire production line



diameter 5.0-12.0(mm)
Welding mesh size 100X100-300X300(mm)
Welding width 2500(mm)





Main Usage:Welding fence meshes for railway, highway, maintain, building meshes for

bridge, road and storey and mine supporting meshes.



PRODUCT FEATURES

1,CNC wheel-step design to provide high accurate mesh grid



2,Electrode lift system to extend electrode life



3,Unique high speed air cylinder used on welding electrode to provide high reliability.



4,Welding pressure steplessly adjustation to apply multiple wire diameter



5,Automatically high speed cross wire feeding system.



TECHNICAL DATA

Model

DNW-CNC2000

DNW-CNC2500

DNW-CNC3000

Installed power(kva)

10*125KVA

12*125

15*125

System coltagte(v)

380V 50Hz

380V 50Hz

380V 50Hz

Control voltage(v)

24V

24V

24V

Max.mesh width

2000

2500

3000

Line wire spacing

≥100mm steplessly adjustable

Cross wire spacing

≥50mm steplessly adjustable

Wire diameter(mm)

5-12

5-12

5-12

Max.welding capacity

12+12

12+12

12+12

Max.wlding speed(time/min)

30-60

30-60

30-60

Max.welding spot nos.(group)

20

25

30

Pressed air(MPa )

≥0.8

≥0.8

≥0.8

Wire feeding method

Pre-cut

Caterconer accutracy

≤2

≤2

≤2

Material

 galvanized wire, cold-rolled ribbed bar or low carbon steel wire













































Each part shows





Refering photos



If you have different requirements other than the above types, please kindly inform us about it and we will offer the

solution for you. Believe that if you are in need of the welding machine, you can get the satisfied ones from us.
