Product detail:
Milk pasteurization machine / Mini pasteurizer machine / Small pasteurizer machine
1.Product introduction
Small pasteurizer machine is also named mini pasteurizer machine
Ideal small milk pasteurization Machine used for yoghourt and milk sterilize and retain freshness .
Small /mini pasteurizer machine equipped with automatic temperature control device, the temperature could be adjusted.
Small /mini pasteurizer machine built in temperature compensating device, could keep water temperature balance.
We supply kinds of stainless steel pasteurizer.
According to the different refrigeration way,they are divided into compressor refrigeration, ice refrigeration, water refrigeration.
According to the different capacity, there are:50kg,100kg,150kg,200kg
The fresh milk and yoghourt two-purpose plate type whole set sterilizing equipment is specially used for pasteurization of fresh milk and yoghourt.
The plates and stainless steel pipes are made of high quality SUS304 stainless steel. The temperature of material inlet is 5°C.The sterilization technology: fresh milk 95°C/15S and yoghourt 95°C/300S. The temperature of material outlet is 5°C/45°C. The system has such functions an high temperature alarm and low temperature return flow, which have strictly
guaranteed that all discharged materials comform to the technology parameters an required.
Main Technical :
Model | AMS-M100 | AMS-M150 |
Internal diameter | 500mm | 640mm |
Output | 100kg/time | 150kg/time |
Material | SUS304 | SUS304 |
Thickness | 1.5 mm | 1.5 mm |
Height | 1650mm | 1650mm |
Sterilization time | 5-40min(adjustable) | 5-40min(adjustable) |
Sterilization temperature | 50-99°C | 50-99°C |
Voltage | 380V/50Hz | 380V/50Hz |
Rate of refrigeration compressor | 9kw | 9kw |
Heat source | electric heating | electric heating |
