Hydraulic Ice Grape Press Machine|Ice Grape Juice Machine|Ice Wine Press Machine

Brand:aa

Product detail:



Hydraulic Ice Grape Press Machine|Ice Grape Juice Machine|Ice Wine Press Machine  0086-18790255066  0086-13838307749







Baskey type ice wine press machine is one of the special equipment for brewing ice wines. This machine is absorbed the technology of Italy. Hydraulic automatic control, then juice dribbling moving wheels, manual hydraulic lift, easy operation. The basket is composed of two semicircles. The wooden structure and stainless steel plate punching two structural forms. The wooden structure of the tradition of the ancient structure of the European brewing ice wine, classic elegance. The structure of the stainless steel plate punching nice. The user can either. Quick opening locking device, easy to operate, fast. The machine for ice grape juice, you can also adapt to any excluding large shaped stone fruit to extract the juice and vegetable processing, to adapt to a wide.



Structure and working principle:



This machine consists of main machine, hydraulic system, mobile juice store plate, the basket.



The juice store plate installed in the frame of dolly with the wheel. The basket is on the juice store plate. After the put grapes into the dolly, then boost it under the mobile platen. The grape will be extruded juice under the pressure of the mobile platen .







Parameters:



Model	GGBPY-1000	GGBPY-800
Capacity	0.7t/h	0.5 t/h
Power	3 KW	3 KW
Working Pressure of Cylinder	≤25Mpa	≤25Mpa
Maxmium Bearable Pressure	≤30Mpa	≤30Mpa
The route of Piston Rod	870mm	700
Diameter of Basket	1000 mm	800
Height of Bsket	1100 mm	950
Volume of Bsket	780L	470L
Dimension	2280×2000×3000mm	1925×1800×2665mm
Weight	1950kg	1600kg
