Low cost brick machine QT6-15 automatic manual hollow block making machine,concrete block factory fo

Brand:aa

Product detail:

1.Low cost brick machine
2.concrete block factory for sale
3.fly ash brick making machine
4.fly ash brick machine



1.Main technical parameters:

Cycle Time	15-20(s)	Total Power	37.4(kw)
Vibration Type	hydraulic vibration	Motor Frequency	50HZ
Machine Dimension	9450×3300×2700(mm)	Pallet Size	850×680×20(mm)
Vibration Force	68KN	Gross Weight	7500(kg)
Rated Pressure	31.5(mpa)	Stacking Machine Power	2.25(kw)





2.Main technical Specifications:

1. It consists of mechanic, electricity and hydraulic in one machine, and it runs automatically in circulation each procedure is interlocked, and the pressure is automatically assigned.

2. Easy to change mechanical action according to different raw materials.

3. Fault self-diagnosis, comport for remote control guarantees technical support and maintenance..



Raw materials :crushed stone ,sand, cement, etc; many type of industrial waste, like, lime, fly ash, slag, coal gangue, gravel, perlite, ect. .

multiple uses, it can produce all type of standard building blocks by changing mould.

1,Multi-holes block and hollow block .

2,Ceram site heat preservation block.

3,Composite heat preservation concrete block

The above production come with good heat preservation performance, and it meets the new national energy conservation policy.

Bricks	Brick sizes	Production per Mold(pcs)	Production per Shift(8 hours)	Picture
Perforated  brick	240x115x90mm	15	21600-28800Pcs
Solid brick	240x115x51mm	30	43200-57600Pcs
Hollow brick	390x190x190mm	6	8640-11520Pcs
Color paver	200x100x60mm	15	21600-28800Pcs





3. QTY6-15A hollow concrete block machine other information:

1. Area: Workshop area: 150-200m2, all factory area 3000m2, the bigger, the better.



2. Workers : two or three



3. Ratio of raw material:cement 8%-10% sand 30%-40% stone:50%-60%,about cement :sand : stone is1:4:5.



4.hollow block weight::



(400*200*200) :17KG,(400*150*200):13.5KG,(400*100*200):10KG



5. raw material consumption per day:160-170T



6. water consumption per day:3%-5% of raw material .Weight.



   4. Production Process:





 5.Production Flow Introduction:



 6.Block & Brick Sample:

7. Product Show:

8. Customer Production Field:
