automatic scanning barcode scanner from factory
Our barcode scanner has super capacity for 1D code, including all kinds of UPC-A, UPC-E, EAN-13, ISBN/ISSN, code 39, codabar, interleaved 25 code,Matrix 25 code, code 128, code11, MSI/PIESSEY,
UK/PLES SEY, UCC/EAN128 code, China post code Etc.
Basic key setting/ serial port/simulation port;
Advance keyboard port/ compatible NOVELL;
Set from your PC keyboard or scanning barcode;
Over 180 parameter option;
Choose output computer automatically;
Over 20 different countries' keyboard;
Set bar code date to any key by keyboard;
Support editing(edit including string, filter, changing form );
Set prefix, suffix and field terminator;
Read/ not read indicator(buzzer and LED);
Use advance decode algorithm;
Oversized ASCII code support code 128;
Low power consumption
Input voltage | DC 5V ±5% |
Power | 258mw(work); 100mw(task state); 380mw(MAX. Peak) |
Source | host machine supply keyboard interface; RS-232 external or host machine supply |
current | 50ma(work);30mw(task state); 100mw(MAX. Peak) |
Light source | Visible laser 650nm |
Electrostatic discharge | 15kv |
Laser grade | State secondary laser safety standard |
Depth of Field | 2-9cm(0.1mm bar width); 3-40cm(0.3mm bar width) |
Scan width | 5cm~30cm |
Decode speed | 120 times/S |
Readable bar width | Min. 0.1mm(4miles) |
Decode capacity | UPC-A, UPC-E, EAN-13, ISBN/ISSN, code 39, codabar, interleaved 25 code, Matrix 25 code, code 128, code11, MSI/PIESSEY, UK/PLES SEY, UCC/EAN128 code, China post code Etc. |
Notice method | Indicator LED, buzzer |
System interface | IBM PS/2 keyboard, IBM PC/XT/AT, RS-232 serial interface; Standard 2.0USB port |
Trigger method | Manual operation; continuous scan automatically; infrared scanning automatically, holder scanning automatically(selectable) |
Dimension | 9.80cm×6.80cm×15.80cm (L*W*H) |
Weight | 135G |
Electric cable standard | Straight line 2m |
Interface type | RJ-45 |
Jacket material | ABS+PC+PVC |
Working temperature | -10°C~60°C |
Storage temperature | -20°C~60°C |
Operation humidity | 0~95% |
Shock resistance | 1.5m free-fall test
|
Language | Multi-language |
Packing: 10 units in a carton box, with each in gift box.
Payment: T/T, Western Union
Lead time: 17 to 20 days.
Price term: FOB Guangzhou, CFR or CIF destination port.
Warranty: 18 months.
OEM is offered.
