howo 10 wheels dump truck

Click for original picture
Drive Wheel: 6x4
Loading Capacity: 25-30t
Horsepower: 336hp/371hp
Fob Price: Discuss personally
Port: main port in China
Supply Ability: 500
Payment Terms: delivery withindays since payment
Location: China Shandong
  Shirley    Contact Now 询价
Not exactly what you want? Post a quick Buying Request !


Product Detail

Brand:howo Sinotruk

Description:his tipper truck is designed for mining /construction use. The maximum capacity is 30 tons and 19.3 cubic. With bottom 8 and side 6 carriage box, the truck is suitable to transport most of the goods such as mineral, sand, construction garbage etc. You can also choose thinner carriage for quarry. The 12.00R20 radial tires are the most cost-effective and perfect for mining environment. Other sizes and radial tires are also available.

Origin:China Shandong

Model:ZZ3255N3647W

MOQ:1Unit/Units

FOB:perUnit/Units37000--38900USD

Port:main port in China

Payment Terms:T/T

Supply Ablility:500Unit/Units

Supply Time:Month

Packaging Details:nude

Product detail: SPECIFICATIONS:

SPECIFICATIONS FOR TIPPER TRUCK

Vehicle Specifications

Model

ZZ3255N3647W

Traction 4X2,6X4,8X4

6X4

Power

371HP

Weight Parameter

Complete Vehicle Kerb Mass(kg)

12010

Maximum authorized total mass (kg)

25000

Dimension Parameter

External Dimensions(mm)

Length (mm)

8214

Width(mm)

2496

Height(mm)

3170

wheelbase(mm)

3600+1350

Internal cargo Sizes

Length (mm)

5600

Width (mm)

2300

Height (mm)

1500

Performance Parameter

Maximum Speed(km/h)

75

Maximum Gradeability(%)

30

Turning diameter(m)

20

Recommended Configuration

Engine

Engine Type

WD615.47

Rated power(kW)/Rev(r/min)

273/2200

Torque(N*m)/Rev(r/min)

1500/1100-1600

Transmission

 HW15710

Clutch(mm)

430

Axle

Front Axle

HF9

Rear Axle

HC16

Fuel Tank(L)

300

Track(mm)

2022+1830

Front overhang/rear overhang(mm)

1550/1740

Tyre

12.00R20

Cabin

Sleeper

no sleeper

OTHER

ABS

optional

COLOR

optional
