Brand:aa
Product detail:
UT351 Sound Level Meters
Skype:efest.service
(welcome to contact me for any question) :)
SPECIFICATIONS
| Measurement Functions | UT351 | ||
|---|---|---|---|
| Total Range | 30 to 130dB | ||
| Maximum Level | 130dB | ||
| Accuracy | ±1.5dB | ||
| Range Selections | 30 to 80dB, 50 to 100dB, 60 to 110dB, 80 to 130dB | ||
| Frequency Range | 31.5Hz to 8000Hz | ||
| Frequency Weighting | A and C | ||
| Time Weighting | FAST (125ms) SLOW (1 second) | ||
| Analogue Bar Graph | 30~130dB | ||
| Warning | Over-Range “OVER”, Under-Range “UNDER” | ||
| Analogue Outputs | AC: 0.707Vrms full scale; Output impedance: around 600 DC: 2Vrms full scale; 10mV/dB; Output impedance around 100 | ||
| Max/Min Mode | |||
| Data Hold | |||
| Display Backlight | |||
| Sleep Mode | |||
| Low Battery Display | 4.8V | ||
GENERAL CHARACTERISTICS
| Power | 1.5V Battery (AA) x 4 |
| LCD Size | 53 x 41mm |
| Product Color | Red and Grey |
| Product Net Weight | 330g |
| Product Size | 273 x 70 x 39mm |
| Standard Accessories | Batteries, English Manual |
| Standard Individual Packing | Gift Box |
| Standard Quantity Per Carton | 30pcs |
| Standard Carton Measurement | 670 x 385 x 300mm (0.077 CBM Per Standard Carton) |
| Standard Carton Gross Weight | 18kg |
